Omega Smart Free-Standing, White Gable-Roof (type 1) Canopy with 16mm Polycarbonate Glazing - 6.3m (W) x 3.5m (P), (8) Supporting Posts



  • Omega Smart Free-Standing, White Gable-Roof (type 1) Canopy with 16mm Polycarbonate Glazing - 6.3m (W) x 3.5m (P), (8) Supporting Posts
  • Buy Omega Smart Free-Standing, White Gable-Roof (type 1) Canopy with 16mm Polycarbonate Glazing - 6.3m (W) x 3.5m (P), (8) Supporting Posts online today
  • Omega Smart Free-Standing, White Gable-Roof (type 1) Canopy with 16mm Polycarbonate Glazing - 6.3m (W) x 3.5m (P), (8) Supporting Posts from Omega Build
  • Great deals on Omega Smart Free-Standing, White Gable-Roof (type 1) Canopy with 16mm Polycarbonate Glazing - 6.3m (W) x 3.5m (P), (8) Supporting Posts
  • Affordable Omega Smart Free-Standing, White Gable-Roof (type 1) Canopy with 16mm Polycarbonate Glazing - 6.3m (W) x 3.5m (P), (8) Supporting Posts
  • Great selection of Omega Smart Free-Standing, White Gable-Roof (type 1) Canopy with 16mm Polycarbonate Glazing - 6.3m (W) x 3.5m (P), (8) Supporting Posts
£ 3312.33 Ex. VAT
£ 3,974.80 Inc. VAT

Glazing Colour

Quantity

Download PDF



Omega Smart Free-Standing, White Gable-Roof (type 1) Canopy with 16mm Polycarbonate Glazing - 6.3m (W) x 3.5m (P), (8) Supporting Posts from Omega Build



Product details:


Canopy Dimensions: 6,306mm(wide) x 3,654mm(projection).

Please note: ‘Width’ is the dimension along the ridge’ and ‘Projection’ is the dimension between the (2) outside edges of the (2) Eaves.

Roof pitch: 20 degrees.

Structural Aluminium (T6) Frame, powder-coated in Brown or White.

16mm Clear, Bronze or Opal Polycarbonate Roof Panels.

Supporting Posts at Eaves 2,850mm.

Foundations for supporting posts require 750mm square x 850mm deep hole back-filled with concrete.

All joints are fitted with Knee-Braces.

Nominal clearance from finished ground level to Tie-bar is 1,975mm (6’6”).

All canopies are supplied with a detailed installation guide.
